Aerial/Duct armored GYTA Outdoor Fiber Optic Cable 2-288 cores

Name: AerialDuct armored GYTA Outdoor Fiber Optic Cable 2288 cores
Brand: Wrc-Aerial/Duct armored GYTA Outdoor Fiber Optic Cable 2-288 cores
Price: 60 USD

China Aerial/Duct armored GYTA Outdoor Fiber Optic Cable 2-288 cores wholesale

Brand Name : Wrc-Aerial/Duct armored GYTA Outdoor Fiber Optic Cable 2-288 cores

Model Number : Aerial/Duct armored GYTA Outdoor Fiber Optic Cable 2-288 cores

Certification : ISO9001,SGS,CIQ

Place of Origin : China

MOQ : 5.0km

Price : USD60-USD350/Km

Payment Terms : Western Union, MoneyGram, D/P, T/T, L/C

Supply Ability : 500Km per day

Delivery Time : 5-21 days

Packaging Details : Export Carton Packing

Application : Telecommunication,Telecom,Network,internet,Lan

Fiber type : G652D,single mode or multi mode,50/125,62.5/125,OM3

Number of conductors : 2,4,8,12,24,48,96,128,288

Type : Single Mode g652d,Outdoor Optical Cable Aerial,Singlemode & Multimode

Fiber count : 2-288 cores

Color : Black,Blue,Grey,Customized,Green,customized

Jacket : PE,MDPE,LSZH,PVC

Name : Aerial/Duct armored GYTA Outdoor Fiber Optic Cable 2-288 cores

Length : 2km,5Km or customized length

Jacket material : PE,LSZH,TPU,LSZH or PVC

Oem : Available

Installation : self- supporting Aerial,aerial, Duct

Structure : Loose tube,Unitube

Operating temperature : -40~75

Sheath material : LSZH,HDPE,PVC

Strength member : steel wire,Aluminum,or as per requirement

Fiber color : Blue,Orange,Brown,Aqua,Grey,Customized

Contact Now

Description: Aerial/Duct armored GYTA Outdoor Fiber Optic Cable 2-288 cores

"Aerial/Duct armored GYTA Outdoor Fiber Optic Cable 2-288 cores" is an outdoor use optical fiber cable suitable for duct and aerial applications. We supply GYTA fiber optic cable from 2 fiber cores to 12 fiber cores. Both single mode type and multimode types are available.

The fibers of 250um, are positioned in a loose tube made of a high modulus plastics. The tubes are filled with a water-resistant filling compound . A fiber Reinforced Wire locates in the center of core as a non-metallic strength member. The tubes (and fillers) are stranded around the strength member into a compact and circular cable core. Then the cable core is covered with a thin Polyethylene (PE) inner sheath, which is filled with jelly to protect it from water ingress. After a corrugated steel tape armor is applied, the cable is completed with a PE outer sheath.

Features

1.Good mechanical and temperature performance
2.High strength loose tube
3.Special tube filling compound ensure a critical protection of fiber
4.Crush resistance and flexibility
5.100% cable core filling
6. PSP enhancing moisture-proof

Structure and Technical specifications of Aerial/Duct armored GYTA Outdoor Fiber Optic Cable 2-288 cores

G.652	G.655	50/125μm	62.5/125μm
Attenuation (+20℃)	@850nm			≤3.0 dB/km	≤3.0 dB/km
	@1300nm			≤1.0 dB/km	≤1.0 dB/km
	@1310nm	≤0.36 dB/km	≤0.40 dB/km
	@1550nm	≤0.22 dB/km	≤0.23dB/km
Bandwidth (Class A)	@850nm			≥500 MHz·km	≥200 MHz·km
Bandwidth (Class A)	@1300nm			≥1000 MHz·km	≥600 MHz·km
Numerical Aperture				0.200±0.015NA	0.275±0.015NA
Cable Cut-off Wavelengthλcc		≤1260nm	≤1480nm

We produce cables according to the standard as below of Aerial/Duct armored GYTA Outdoor Fiber Optic Cable 2-288 cores

Mechanical Performance
Max Tension Performance	IEC 60794–1-2-E
Max. Operation Tension	IEC 60794–1-2-E1
Crush Test	IEC 6079 –1-2-E3
Impact Test	IEC 60794–1-2-E4
Repeated Bending	IEC 60794–1-2-E6
Torsion Test	IEC 60794–1-2-E7
Cable bend	IEC 60794–1-2-E11A
Attenuation Coefficient	ITU-T G.652
Structural Test	IEC-60793-1-20
Environmental Performance
Temperature Cycling	IEC 60794–1-2-F1
Water Penetration	IEC 60794–1–2-F5B
Filing Compound Flow	IEC 60794-1-E14

FAQ

Q1: Are you a factory or trading company?
A1: We are a manufacturer.

Q2: May I buy samples from you?
A2: Yes! You are welcome to place sample order to test our superior quality and service

Q3:How to Place an order?
A8:Pls send us your purchase order by email or you can ask us to send you the proforma invoice for your order.

Q4:What payment method do you accept?
A4:T/T(Bank transfer), L/C, Western Union, Money Gram, PayPal, etc.

Q5: May I know the status of my order?
A5: Yes .The order information and photos at different production stage of your order will be sent to you and the information will be updated in time.

Q6: What’s the leading time? (How long do you need to prepare my goods?)
A6: Delivery (no more than 1000pcs) will be arranged within 3-7 days after payment.Big order shall be in 7-30 days.

Q7: How will you delivery my goods ?
A7: It will be delivered by DHL, UPS, FedEx, TNT, EMS your door. Air Cargo and Sea Cargo.

Drawings of Aerial/Duct armored GYTA Outdoor Fiber Optic Cable 2-288 cores

Aerial/Duct armored GYTA Outdoor Fiber Optic Cable 2-288 cores

Package of Aerial/Duct armored GYTA Outdoor Fiber Optic Cable 2-288 cores

More products customized

Aerial/Duct armored GYTA Outdoor Fiber Optic Cable 2-288 cores

Aerial/Duct armored GYTA Outdoor Fiber Optic Cable 2-288 cores Images
