Self Supporting GYTC8A GYTC8S 12 24 96 Core Aerial Fiber Optic Cable

  • 1
  • 2
  • 3

Brand Name : WRC-Self-supporting figure 8 GYTC8A 12/24/96core aerial fiber optic cable GYTC8S

Model Number : Self-supporting figure 8 GYTC8A 12/24/96core aerial fiber optic cable GYTC8S

Certification : ISO9001/CE

Place of Origin : China

MOQ : 2000 Meters

Price : USD240-USD1550/Km

Payment Terms : Western Union, MoneyGram, T/T, L/C

Supply Ability : 1000 Km per Day

Delivery Time : 5-20 days

Packaging Details : Export Carton Packing

Name : Self-supporting figure 8 GYTC8A 12/24/96core aerial fiber optic cable GYTC8S

Fiber type : G652D

Fiber count : 24F

Type : Fiber Optic Cable

Cable Diameter : 9.8*18.5mm

Strength member : Steel wire

Installation : Self-supporting/Aerial

Application : Long distance communication system

Messenger member : Steel wire

Fiber options : ITU G652D ,G657A,OM1,OM2,OM3,OM4

Color : Customized

Contact Now

Self-supporting figure 8 GYTC8A 12/24/96core aerial fiber optic cable GYTC8S

Description of Self-supporting figure 8 GYTC8A 12/24/96core aerial fiber optic cable GYTC8S

GYTC8S is a typical outdoor use fiber optic cable for aerial applications; GYTC8S is also called the figure 8 cable because of its structure looks like the figure 8. We supply single mode and multimode GYTC8S fiber cables from 2-fiber type to 96-fiber type.

Features of of Self-supporting figure 8 GYTC8A 12/24/96core aerial fiber optic cable GYTC8S

1,High tensile strength of stranded wires meet the requirement of self-supporting and reduce the installation cost.

2,Good mechanical and temperature performance.

3,Self-supporting Figure 8 design.

4,Special tube filling compound ensure a critical protection of fiber
5,Loose tube filling compound
6,Aramid Yarn Provide additional mechanical protection
7,Loose tube filling compound
8,100% cable core filling

9,Loose tube gel-filled construction for superior fiber protection.
10,UV and moisture-resistant design

Parameter Data of Self-supporting figure 8 GYTC8A 12/24/96core aerial fiber optic cable GYTC8S

Fiber Num.
Outer diameter (mm)
Weight (kg/km)
Tension (N)
Crash loading(N/100mm)
Short term
Long term
Short term
Long term
2-30
9.5*18.2
150
≥6000
≥2000
≥1000
≥300
32-48
10.2*18.9
162
50-60
10.2*19.2
173
62-72
10.9*19.9
197
74-84
12.1*21.1
217
86-96
12.1*21.1
217

Mechanical and Environmental Characteristics:

Items Unite Specifications
Tension(Long Term) N 300
Tension(Short Term) N 800
Crush(Long Term) N/10cm 200
Crush(Short Term) N/10cm 600
Min. Bend Radius(Dynamic) mm 20D
Min. Bend Radius(Static) mm 10D
Installation Temperature ºC -20~+60
Operating Temperature ºC -40~+70
Storage Temperature ºC -40~+70

G.652D Single Mode Optical Fiber (B1.3)
Item
Standard
Unit
Attenuation
1310nm
≤0.35
dB/km
1383nm
≤0.33
dB/km
1550nm
≤0.21
dB/km
1625nm
≤0.24
dB/km
Dispersion
1288nm～1339nm
|D|≤3.4
ps/(nm·km)
1271nm～1360nm
|D|≤5.3
ps/(nm·km)
1550nm
≤17.8
ps/(nm·km)
Zero-dispersion wavelength
1300～1322
(nm)
Zero-dispersion slope
≤0.091
ps/(nm2•km)
PMD
PMD single fiber
≤0.15
ps/√km
PMD Q links
≤0.08
ps/√km
MDF
1310nm
9.2±0.4
um
Cladding diameter
125±1.0
μm
Cladding non-circularity
≤0.8
%
Core-cladding concentricity error
≤0.6
μm
Coating diameter
245±10
μm
Cladding/coating concentricity error
≤10.0
μm
Cut-off wavelength
1.18～1.33
μm
Macrobend attenuation
(ф 50mm, 100 cycles)
1550nm
≤0.05
dB
1625nm
≤0.05
dB
Bending radius
≥5
m
Dynamic fatigue parameters
≥20
nd
Additional Attenuation
@1310nm &
@1550nm
Temperature cycling test:
(-60℃～85℃, 3 cycles)
≤0.03
dB/km
Water soak test:
(23℃ for 30 days)
≤0.03
dB/km
Damp heat test:
(85℃, 85%RH for 30 days)
≤0.03
dB/km

Thermal aging test

(85℃ for 30 days)
≤0.03
dB/km
Warm water soak test: (60℃ for 15 days)
≤0.03
dB/km

Drawings of Self-supporting figure 8 GYTC8A 12/24/96core aerial fiber optic cable GYTC8S

Self Supporting GYTC8A GYTC8S 12 24 96 Core Aerial Fiber Optic Cable
